This PI System plugin provides a real-time calculation and polar plot of exhaust gas temperatures and maps to the originating combustion chamber. It uses the exhaust swirl angle to correct the combustion chamber position so that each exhaust thermocouple points to the correct combustion chamber.
The visual map of the exhaust temperatures makes it easy to identify uneven temperatures distributions and determine the source combustion chamber associated with the given downstream thermocouples.
(PPI-CCP-CTG-ETP)
